Foundry

Processes and Technologies

Teledyne DALSA, together with sister foundry Teledyne Micralyne, offers customers a truly unmatched toolbox of dozens of proven and patented process modules and techniques in both 150 and 200 mm lines. We are proud of our toolbox, but even more proud of our mastery of it. The greatest value we offer you is our ability to leverage and integrate individual foundry processes to bring your breakthrough MEMS designs into production.

Teledyne DALSA's 200 mm MEMS line has been installed to provide capacity for higher volume production, and to support wafer level bonding of MEMS to 200 mm CMOS wafers. There is a high degree of commonality between our 150 mm and 200 mm MEMS lines, and most applications which run on 150 mm can be transferred to 200 mm if required.

Lithography

5X front to front (ASML) 0.35 µm feature, 0.1 µm accuracy
5X front to back (ASML) 0.35 µm feature, 0.2 µm accuracy
1x front to front 3.0 µm feature, 0.5 µm accuracy
1x front to back 3.0 µm feature, 0.75 µm accuracy

Positive & negative resists

Dry film lamination of photo-definable thick polymers
Spin coating of thin and thick photoresists and photopolymers

Plasma Deposition

PECVD TEOS, nitride.

Dicing

Automated taping/dicing
UV backing and cover tapes.

Ion Implantation

Low Current , High Current
Species: B, BF₂, P, As. Energy : 30 keV to 200 keV

Wafer Bonding

Si-Si, Si-SiO₂, glass frit, anodic, Al-Ge eutectic, polymer

Wafer Thinning

Backgrind, CMP, edge grind

Metallization

Sputter Al, AlCu, AlSiCu, Ti, TiN, Ge, SiCr
CVD Tungsten
Electroless Plating Ni/Pd, Ni/Au

Metrology (in-line)

ACV4, CD-SEM, ellipsometer, interferometer
Spectroscopic reflectometer, surfscan
August NSX

Furnaces : Horizontal, Vertical

Wet/dry oxidation
POCL doping
Nitride (including low stress)
LPCVD oxide (LTO, SG/PSG, TEOS)
LPCVD silicon (poly, amorphous, in-situ doped)
SAM coating

Test

Keithley Parametric testers
MEMs electrical, optical and acoustic testing
Test development service for MEMs
Customer specific test systems
